0200FR
Class A EPDM-Alternative
The World's first and only.
0200FR
Overview
The OBEX CORTEX 0200FR Class A2 Interface Sealing Membrane is the first ‘EPDM-alternative’ to achieve a fire classification of A2-s1,d0. It also has full BBA approval.
This quality membrane is used in conjunction with OBEX CORTEX 0210FR Class A2 Paste Adhesive, making it the first and only Class A sealing system for windows and facades.
Water Resistance
CORTEX 0200FR is a highly water-resistant membrane. It passes the water-tightness requirement of 2kPa of water for 24 hours when tested to EN13984.
| WATERTIGHTNESS | Pass – 2kPa for 24 hours |
Class A
CORTEX 0200FR has a fire classification of Class A2-s1,d0 when tested to EN13501-1, and as such, is the first window-sealing membrane to meet the requirements of Regulation 7, for buildings over 18 metres tall.
| FIRE CLASSIFICATION | A2-S1, D0 / EN13501-1 |
Technical Specification
| Harmonised Standard | EN 13984 |
| Fire Classification
EN 13501-1 | A2-s1,d0 |
| Tensile strength
EN 12311-1 | MD 7767N/50mm
CD 3973 N/50mm |
| Watertightness
EN 1928 | Pass – 2 kPa for 24 hours |
| Tear Strength (nail shank)
EN 12310-1 | MD 519N
CD 436N |
| Air Tightness
EN 12114 | <0.1m³ |
Product Specification
| Widths | 50 – 1500mm |
| Length | 20m |
| Thickness | 0.4mm |
| 3rd Party Certification | Full BBA Approval |
| Building Height Suitability | Recommended for all buildings. Mandatory for buildings taller than 11m |
| Related Product | OBEX CORTEX 0210FR Class A2 Paste Adhesive |
Compliance
OBEX CORTEX 0200FR Class A Membrane is the world’s first, Class A façade sealing membrane that’s fully compliant with Regulation 7 and Approved Document B ;
“Building work shall be carried out so that materials which become part of an external wall, or specified attachment, of a relevant building are of European Classification A2-s1,d0 or A1”
Reliability
We offer free-of-charge Site Support, Installation Training, QA Inspections & Certifications, and orders placed by 3pm will be dispatched for next working day delivery.
